What we know of the Mercedes EQA

EQA
3.41KViews

EQA is the name of the new entry-level model to the all-electric world of Mercedes-EQ vehicles. The electro-aesthetics of its design are indicative of the Progressive Luxury of the Mercedes-EQ brand. Smart assistants support the driver in many areas: for example with respect to accident avoidance, the anticipatory and therefore particularly efficient operating strategy, and Navigation with Electric Intelligence.

In addition, the car features various exceptional Mercedes-Benz functions, such as MBUX (Mercedes-Benz User Experience). The EQA is a member of the successful compact car family from Mercedes-Benz. A close relation of the GLA, it delivers all the thrilling characteristics of that vehicle, combined in this case with an efficient electric powertrain.

EQA

The new EQA is being built in Rastatt (Germany) and Beijing (China). The battery systems for the EQA are supplied by the Mercedes-Benz subsidiary Accumotive in Kamenz. The battery factory in Jawor, Poland, is also preparing to produce battery systems for the compact Mercedes-EQ models.

The EQA is being launched as the EQA 250 (combined electric consumption: 15.7 kWh/100 km; combined CO2 emissions: 0 g/km)[1] with 140 kW and a range according to NEDC of 486 kilometres[2]. The “double-decker” lithium-ion battery, which sits as a structural element within the underbody of the vehicle, has an energy content of 66.5 kWh. In order to meet the high standard of noise and vibration comfort that is such a hallmark of the brand, complex measures have been taken to isolate the electric powertrain from the chassis and body. Numerous damping measures enhance this effect.

EQA Exterior Design:

The EQA features the black panel radiator grille with central star that is the hallmark of Mercedes-EQ. A further distinctive design feature of the all-electric world of Mercedes-EQ vehicles is the continuous light strip at front and rear.

EQA

A horizontal fibre-optic strip connects the daytime running lights of the full-LED headlamps, ensuring a high level of recognisability both in daylight and at night. The inside of the headlamps is finished to a high level of quality, detail and precision. Blue colour highlights within the headlamp reinforce the signature Mercedes-EQ appearance.

EQA

The LED tail lamps merge seamlessly into the tapered LED light strip, thus underlining the impression of width in the rear view of the EQA.

The licence plate has also been relocated to the bumper. Exclusive to this model are light-alloy wheels in a bi- or tri-colour design, up to 20 inches in size, in some cases with rosé gold-coloured or blue decorative trim.

EQA Interior Design:

An indication of the electric character in the interior of the EQA is provided, depending on the design and equipment line, by a new-style back-lit trim element and rosé gold-coloured decorative trim on the ventilation outlets, seats and the vehicle key.

EQA

The Edition 1 special model additionally features perforated leather seats, through which blue fabric can be seen. The instruments, with their electric car-specific displays, pick up on the same colour scheme with rosé gold-coloured and blue highlights.

The seating position is high and upright, as is typical for an SUV – making it not only comfortable for getting in and out, but also good in terms of all-round visibility. Utility value was one of the general focuses during development. The rear seat backrest is 40:20:40 split-folding.

Efficiency is the key factor, from the aerodynamics through to Navigation

With a Cd value from 0.28, the EQA achieves an excellent result. The frontal area A totals 2.47 m2. Among the most important aerodynamic measures are the completely closed cooling air control system in the upper section, the aerodynamically efficient front and rear aprons, a very smooth, almost completely enclosed underbody, specially optimised Aero wheels and specifically adapted front and rear wheel spoilers.

The standard heat pump forms part of the sophisticated thermal management system. With its numerous innovative details, such as the reuse of the waste heat from the electric drive system, the system is configured for exceptional efficiency and thus maximum range. It is also possible to set the pre-entry climate control for the interior of the EQA before starting. This function is controlled directly from the MBUX infotainment system or via the Mercedes me App.

Adding to the general ease of using the EQA on a day-to-day basis is the standard feature of Navigation with Electric Intelligence. This calculates the fastest route to the given destination. On the basis of continual range simulations, the system makes allowance for any necessary charging stops as well as for numerous other factors, such as the topography and the weather. It is also able to react dynamically to changes, for instance in the traffic situation or personal driving style.

Technical data[3]:

    EQA 250
Drive system layout Front
Electric motor, front axle Model Asynchronous motor
Rated output kW 140
Rated torque Nm 375
Acceleration 0-100 km/h s 8.9
Top speed[4] km/h 160
Battery capacity, usable (NEDC) kWh 66.5
Combined fuel consumption (NEDC)[5] kWh/100 km 15.7
NEDC range3 km 486
Charging time[6] at wallbox or at public charging stations (AC charging) h 5:45
Charging time[7] at rapid-charging station (DC) min 30

Intelligent driving assistance systems with cooperative support from the driver, exceptional crash safety

Included as standard on board are Active Lane Keeping Assist and Active Brake Assist. In many situations the purpose of the latter is to prevent a collision by autonomous braking, or to mitigate its consequences. The system is also able to brake for stationary vehicles and crossing pedestrians at typical city speeds. The enhanced functions of the Driving Assistance Package include, for example, the turning manoeuvre function, the emergency corridor function, the exit warning function alerting the driver to approaching cyclists or vehicles, and a warning when pedestrians are detected near zebra crossings.

The EQA is also a true Mercedes when it comes to passive safety. On the basis of the robust structure of the GLA, the body of the EQA was adapted to meet the particular demands that face an electric car. The battery sits within a frame made out of extruded sections. This takes on a structural function which until now was handled by the cross members in the underfloor. A battery guard in the front area of the battery is able to prevent the energy storage unit from being pierced by foreign objects. Naturally the EQA also had to go through the brand’s normal and very thorough crash test programme. Stringent requirements for the battery and all components carrying electrical current also apply.

Superior level of equipment, instruments with displays specific to Mercedes-EQ

Included as standard is the intuitively operated MBUX infotainment system (Mercedes-Benz User Experience). MBUX can be individually configured with the help of various options. Key advantages of the system: the powerful computer, brilliant screens and graphics, customisable presentation, full-colour head-up display (optional equipment), navigation with augmented reality (optional equipment), learning software and voice control activated by the keyword “Hey Mercedes”.

The Mercedes-EQ tile in the media display can be used to call up menus relating to charging options, electrical consumption and energy flow. The right-hand display within the instrument cluster is a wattmeter rather than a rev counter. The upper section shows the percentage of power used, the lower section the recuperation. The left-hand instrument can be used to show whether the destination can be reached without an interim charging stop. The colours change according to the driving situation: During a boost process, for example, the display changes to white. Depending on mood, or to match the particular interior, the user has a choice of four different styles. The Progressive variant includes a special Mercedes-EQ colour scheme

The comprehensive standard specification of the EQA includes such features as LED High Performance headlamps with Adaptive Highbeam Assist, the EASY-PACK tailgate with electrically operated opening and closing, 18-inch light-alloy wheels, ambient lighting with 64 colours, a double cup holder, luxury seats with four-way adjustable lumbar support, a reversing camera for added convenience and a better overview when manoeuvring, and a multifunction sports steering wheel in leather. The new model can be personalised with either of the two design and equipment lines AMG Line and Electric Art, as well as with the Night Package.

The electrical consumption and the range have been determined on the basis of Commission Regulation (EC) 692/2008. The power consumption is dependent upon the vehicle configuration. Further information on the official fuel consumption and the official specific CO2 emissions of new passenger cars can be found in the “Leitfaden über den Kraftstoffverbrauch, die CO2-Emissionen und den Stromverbrauch neuer Personenkraftwagen” [Guide on the fuel economy, CO₂ emissions and power consumption of all new passenger car models], which is available free of charge at all sales outlets and from Deutsche Automobil Treuhand GmbH at www.dat.de.

[2] According to WLTP the figure is 426 kilometres.

[3] The WLTP figures for the models listed applicable to the German market can be found at the end of the section. This information can be retrieved on a market-by-market basis from the relevant national Mercedes-Benz websites.

[4] Electronically limited

[5] Power consumption and range have been determined on the basis of Commission Regulation (EC) 692/2008. Power consumption and range depend on the vehicle configuration. Further information on the official fuel consumption and the official specific CO2 emissions of new passenger cars can be found in the “Leitfaden über den Kraftstoffverbrauch, die CO2-Emissionen und den Stromverbrauch neuer Personenkraftwagen” [Guide on the fuel economy, CO₂ emissions and power consumption of all new passenger car models], which is available free of charge at all sales outlets and from Deutsche Automobil Treuhand GmbH at www.dat.de.

[6] The charging times are for a 10-100% full charge at a wallbox or public charging station (AC connection with at least 11 kW, 16 A per phase)

[7] The charging times are for 10-80% full charge at a DC rapid charging station with a supply voltage of 400 V, current at least 300 A.
